Chiller Trailer for Meat and Vegetables Interior
Description of Chiller Trailer for Meat and Vegetables Interior
The high‑performance refrigeration system maintains a precise temperature range of -2°C to 8°C, with uniform airflow across the entire cargo space to preserve freshness, texture, and quality. Reinforced galvanized meat rails are integrated into the ceiling for hanging carcasses and cuts, while the ventilated, non‑slip aluminum floor supports palletized vegetables, promotes air circulation, and speeds up cleaning and drainage.
Sealed door gaskets minimize temperature fluctuation during loading and unloading. LED interior lighting, digital temperature monitoring, and optimized air ducts deliver consistent cooling without dry‑out or cold spots. The design combines heavy‑duty durability with hygienic functionality, making it ideal for dual‑purpose meat and produce cold chain logistics.
Core characteristics of Chiller Trailer Container Cold Room
Super Mobility & Flexible Deployment
This product is based on a professional trailer chassis, equipped with a reliable traction mechanism, brake system and lighting system, which can be quickly towed by trucks to any site that needs cold storage support. It does not need to build a fixed foundation, and can be put into use immediately after arriving at the destination, which greatly shortens the preparation time of cold chain services. It can realize cross-regional transfer and temporary cold storage in festivals, emergency supply, outdoor activities and disaster relief scenarios. At the same time, it is compatible with standard container hoisting and transportation modes, and can be transported by land and sea, realizing seamless connection of multi-scenario and multi-mode transportation. Its flexible deployment ability breaks the limitation of fixed cold storage, and provides a movable low-temperature guarantee for decentralized and mobile cold chain demands.
Excellent Thermal Insulation & Sealing Performance
The box is made of high-density polyurethane (PUR/PIR) integral foaming insulation board, with a thickness of 80mm-150mm, which has extremely low thermal conductivity and can effectively block external heat invasion and reduce cold loss. The board is connected by a special concave-convex bite structure, and the whole box is sealed with food-grade sealant, so there is no cold bridge or air leakage. The exterior wall is made of corrugated galvanized steel plate or stainless steel, which is anti-corrosion, anti-aging and UV-resistant; the interior wall is made of food-grade FRP or stainless steel plate, which is smooth, non-toxic and tasteless, and easy to clean. The door adopts a double-layer sealing structure with a heavy-duty door hinge and a self-locking door handle, which ensures tight fit when closed and maintains the stability of the internal temperature and humidity environment. Excellent thermal insulation and sealing can reduce the operating load of the refrigeration unit, save energy consumption, and extend the continuous cooling time.
Precise Temperature Control & Wide Adaptability
It is equipped with an imported or domestic high-performance air-cooled refrigeration unit, with a variable frequency compressor and an intelligent temperature control system. The temperature control range is wide, generally +25℃ to -25℃, and can be customized to -40℃ ultra-low temperature version according to demand. It can realize stepless adjustment of cooling and heating, and is suitable for fresh-keeping (0℃~10℃), freezing (-18℃~-25℃) and constant temperature storage of different goods. The built-in strong circulation fan and air duct system make the cold air circulate evenly in the box, and the temperature difference in the box is controlled within ±1℃, avoiding local overcooling or overheating and ensuring the quality stability of goods. It can adapt to high temperature, high humidity, severe cold and other harsh outdoor environments, and maintain stable cooling effect under complex working conditions.
Robust Structure & Long Service Life
The whole box adopts a frame-type reinforced structure, with high-strength steel beams at the bottom and corners, which has strong compression, bending and impact resistance, and can withstand the extrusion and vibration during long-distance transportation. The floor is made of aluminum alloy T-slot or stainless steel non-slip floor, which has high bearing capacity, is convenient for forklift and pallet operation, and is conducive to air circulation and water drainage. The chassis, frame and metal parts are treated with anti-corrosion and anti-rust, which can resist rain, salt fog and chemical corrosion, and adapt to coastal and humid areas. The modular design of the equipment makes the maintenance of the refrigeration unit, circuit and control system simple and fast, reduces the failure rate and maintenance cost, and the normal service life can reach more than 10 years.
· PrFood processing workshops
· Cold stores and freezer rooms
· Cold chain logistics centres and distribution warehouses
· Pharmaceutical factories and cleanrooms
· Biological laboratories and sample repositories
· Flower preservation chambers
· Low-temperature storage for
| Product Type |
Chiller Trailer for Meat and Vegetables Interior |
|
Applicable Industries |
Restaurant, Retail, Food Shop, Food & Beverage Shops |
|
After Warranty Service |
Video technical support, Online support |
|
Voltage |
110V/220V/380V |
|
Power |
5-20 kW |
|
Refrigeration Capacity |
10-50 kW (34,000-170,000 BTU/h) |
|
Temperature Range |
-20°C to 10°C (-4°F to 50°F) |
|
Material |
Galvanized Steel |
|
Floor |
Non-slip Flooring (aluminum) with Drain |
|
Wheels |
2/4 Wheels |
|
Evaporator |
Air Cooled (Ceiling Mounted, Floor Mounted) |
|
Certification |
CE,ISO |
|
Service Door |
Customized |
|
Insulation Thickness |
50mm (2in) |
|
Specification |
Customized |
Frequently Asked Questions (FAQ)
1. What is a mobile refrigerated trailer?
A mobile refrigerated trailer (often called a "reefer trailer" or "cool room on wheels") is a towable insulated unit equipped with a refrigeration system. It is designed to transport or store temperature-sensitive goods like food, beverages, flowers, and pharmaceuticals.
2. Can this trailer be used as both a cooler and a freezer?
Yes, most of our units are equipped with adjustable refrigeration systems. You can set the temperature to keep items chilled (0°C to 4°C) or deep-frozen (-18°C or lower), depending on your needs.
3. What are the main applications for this trailer?
Common uses include outdoor catering events, emergency backup for restaurants, transporting fresh produce for farmers, game meat storage for hunters, floral delivery, and cold chain logistics for medical supplies.
4. Is the trailer suitable for long-distance travel?
Absolutely. The trailer is built on a heavy-duty chassis with a suspension system designed for highway speeds and long-distance transport.
5. How is the refrigeration unit powered?
The unit typically runs on standard single-phase AC power (110V or 220V, depending on your region). It can be plugged into a standard wall outlet or powered by a portable generator.
6. Does the refrigeration unit run while the vehicle is towing it?
Standard electric units require a generator mounted on the trailer tongue or in the towing vehicle to run while in motion. Alternatively, the high-quality insulation keeps goods cold for shorter trips without power.
7. How long does it take to reach the desired temperature?
An empty trailer typically pulls down to 0°C (32°F) within 30 to 60 minutes, depending on the ambient temperature and the power of the cooling unit.
8. How much power does the unit consume?
Power consumption varies by model, but most compact units are energy-efficient, drawing between 10 to 15 amps during startup and significantly less while running.
9. Is there a backup power option?
We recommend using a portable generator (usually 3.5kW or higher) as a backup power source if shore power is unavailable.
10. What kind of vehicle do I need to tow this trailer?
Our single-axle compact models are lightweight and can be towed by most standard SUVs, pickup trucks, and even some sedans. Please check your vehicle's towing capacity against the trailer's Gross Vehicle Weight (GVW).
11. Do I need a special driver’s license to tow this?
For most small to medium-sized trailers (under 3,500kg or 7,700lbs), a standard driver’s license is sufficient. However, regulations vary by country and state, so please check local laws.
12. What type of connection does the trailer lights use?
We install standard 7-pin (round) or flat connectors adaptable to most vehicles.
13. What is the payload capacity?
Payload depends on the specific axle rating. A standard single-axle unit typically carries between 500kg to 1,000kg (1,100lbs to 2,200lbs). Heavy-duty options are available.
14. What material is the insulation made of?
We use high-density Polyurethane (PU) sandwich panels (typically 75mm to 100mm thick), which offer superior thermal efficiency compared to Styrofoam.
15. Is the floor slip-resistant?
Yes, the floor is typically finished with checkered aluminum plate (diamond plate) or an anti-slip resin coating to ensure safety during loading and unloading.
16. Does it come with internal shelving?
Shelving is optional. We can install stainless steel or food-grade wire racking, or leave the space open for pallet storage.
17. Is the interior light waterproof?
Yes, the trailer comes equipped with an IP65-rated LED internal light for safe operation in wet and cold conditions.
18. Are the doors lockable?
Yes, the rear doors feature heavy-duty stainless steel cam-locks that are fully lockable to secure your valuable cargo.
19. Is there an emergency release inside?
Safety is a priority. All our walk-in trailers feature an internal safety release mechanism, allowing anyone trapped inside to open the door easily.
20. How do I clean the interior?
The interior panels are seamless and water-resistant. You can wash them down with mild detergent and water. A floor drain is usually included for easy washout.
21. How often does the refrigeration unit need servicing?
We recommend a basic check-up (cleaning condenser coils, checking refrigerant levels) once a year or every 6 months if used heavily.
22. What should I do if the unit stops working?
Check your power source and breakers first. If the issue persists, our units are made by major manufacturers (like Govi, KingClima, or Carrier), so parts and service technicians are widely available.
23. Can I customize the size or color?
Yes, we offer OEM/ODM services. We can customize dimensions, door placement, exterior wrap/branding, and chassis specifications.
24. What is the warranty period?
We typically offer a 1-year warranty on the trailer chassis and body, and a separate warranty (usually 1 year) from the refrigeration unit manufacturer.
25. Do you ship internationally?
Yes, we ship worldwide. Trailers can be shipped fully assembled (CBU) or in flat-pack (CKD) form to save on shipping costs.
