Modular Chiller Mobile Room Trailer
Description of Modular Chiller Mobile Room Trailer
Our Modular Chiller Mobile Room Trailer is a fully integrated, plug‑and‑play mobile cooling solution built for on‑demand, relocatable temperature control. Combining a high‑efficiency modular chiller unit with a rugged, insulated trailer enclosure, it delivers stable, scalable cooling for temporary events, emergency backup, construction sites, logistics, food processing, pharmaceuticals, and industrial process cooling.
Designed for mobility and durability, the unit features a heavy‑duty steel frame, weatherproof housing, and high‑performance PU/PIR insulated panels to minimize energy loss and maintain precise temperature control. The modular chiller design supports flexible capacity tuning, energy‑efficient partial‑load operation, and stable running with low noise and vibration.
Core characteristics of Modular Chiller Mobile Room Trailer
Revolutionary Integrated Mobile Design: Unmatched Mobility and Flexibility
At the core of the Modular Chiller Mobile Room Trailer lies its groundbreaking integrated mobile structure, which combines a high-efficiency modular chiller unit, a thermally insulated room, and a heavy-duty trailer chassis into a single, cohesive system. This all-in-one design eliminates the need for complex on-site assembly or permanent installation, allowing the unit to be towed effortlessly between job sites, warehouses, event venues, or emergency locations using standard towing vehicles. The trailer is engineered with a robust steel frame that ensures structural integrity during transportation, while its compact footprint minimizes space requirements for both transit and deployment.
Advanced Modular Cooling Technology: Scalable and Energy-Efficient Performance
The Modular Chiller Mobile Room Trailer is equipped with a state-of-the-art modular chiller system that represents the pinnacle of cooling technology. Modular design enables flexible capacity configuration, allowing businesses to adjust cooling output based on real-time demand. Whether requiring 50% capacity for light cooling or 100% full capacity for intense industrial processes, the unit can seamlessly scale its performance to match specific needs. This not only optimizes energy consumption but also extends the lifespan of components by avoiding continuous high-load operation. Powered by high-efficiency compressors and heat exchangers, the chiller unit delivers exceptional cooling capacity while maintaining exceptional energy efficiency. It incorporates advanced inverter technology, which adjusts the compressor speed dynamically to maintain precise temperature levels, resulting in significant energy savings compared to fixed-speed chiller systems. Additionally, the modular design supports parallel operation of multiple units, enabling businesses to expand their cooling capacity incrementally as their needs grow—eliminating the need for costly full-system overhauls.
Precision Temperature Control: Ensuring Consistency and Quality
For industries where temperature stability is non-negotiable—such as food processing, pharmaceuticals, cold storage, and industrial manufacturing—the Modular Chiller Mobile Room Trailer offers unparalleled temperature precision. The system is equipped with an intelligent digital control panel that allows users to set and monitor temperature parameters with accuracy up to ±0.1°C. Real-time temperature data is displayed clearly on the interface, enabling continuous tracking and adjustment. To guarantee consistent performance, the chiller unit integrates multi-stage safety protection systems, including over-temperature, over-pressure, low-pressure, and antifreeze protection. These features prevent equipment damage due to extreme operating conditions and ensure stable 24/7 operation. The control panel also supports timing functions and automated cycle adjustment, enabling users to program pre-set cooling schedules for automated operations—perfect for round-the-clock industrial processes or event cooling that requires consistent temperature maintenance over extended periods.
High-Performance Insulated Enclosure: Maximizing Thermal Efficiency
The trailer’s insulated room is constructed with premium PU/PIR insulated panels, renowned for their exceptional thermal insulation properties. These panels are engineered with a high-density foam core that minimizes heat transfer, effectively maintaining the internal temperature and reducing cooling load. The panels are bonded with high-strength adhesives and feature seamless joints to prevent air leakage, ensuring optimal thermal efficiency even in extreme outdoor environments. The enclosure is designed to withstand harsh weather conditions, with a waterproof, dustproof, and corrosion-resistant outer shell that protects the internal chiller system and insulation structure. Whether exposed to scorching heat, heavy rain, or freezing cold, the insulated room maintains its thermal performance, ensuring the chiller unit operates at peak efficiency regardless of external weather conditions. This durability makes the trailer suitable for outdoor deployment in construction sites, outdoor events, and emergency cooling applications across diverse geographical regions.
· PrFood processing workshops
· Cold stores and freezer rooms
· Cold chain logistics centres and distribution warehouses
· Pharmaceutical factories and cleanrooms
· Biological laboratories and sample repositories
· Flower preservation chambers
· Low-temperature storage for
| Product Type |
Modular Chiller Mobile Room Trailer |
|
Applicable Industries |
Restaurant, Retail, Food Shop, Food & Beverage Shops |
|
After Warranty Service |
Video technical support, Online support |
|
Voltage |
110V/220V/380V |
|
Power |
5-20 kW |
|
Refrigeration Capacity |
10-50 kW (34,000-170,000 BTU/h) |
|
Temperature Range |
-20°C to 10°C (-4°F to 50°F) |
|
Material |
Galvanized Steel |
|
Floor |
Non-slip Flooring (aluminum) with Drain |
|
Wheels |
2/4 Wheels |
|
Evaporator |
Air Cooled (Ceiling Mounted, Floor Mounted) |
|
Certification |
CE,ISO |
|
Service Door |
Customized |
|
Insulation Thickness |
50mm (2in) |
|
Specification |
Customized |
Frequently Asked Questions (FAQ)
1. What is a mobile refrigerated trailer?
A mobile refrigerated trailer (often called a "reefer trailer" or "cool room on wheels") is a towable insulated unit equipped with a refrigeration system. It is designed to transport or store temperature-sensitive goods like food, beverages, flowers, and pharmaceuticals.
2. Can this trailer be used as both a cooler and a freezer?
Yes, most of our units are equipped with adjustable refrigeration systems. You can set the temperature to keep items chilled (0°C to 4°C) or deep-frozen (-18°C or lower), depending on your needs.
3. What are the main applications for this trailer?
Common uses include outdoor catering events, emergency backup for restaurants, transporting fresh produce for farmers, game meat storage for hunters, floral delivery, and cold chain logistics for medical supplies.
4. Is the trailer suitable for long-distance travel?
Absolutely. The trailer is built on a heavy-duty chassis with a suspension system designed for highway speeds and long-distance transport.
5. How is the refrigeration unit powered?
The unit typically runs on standard single-phase AC power (110V or 220V, depending on your region). It can be plugged into a standard wall outlet or powered by a portable generator.
6. Does the refrigeration unit run while the vehicle is towing it?
Standard electric units require a generator mounted on the trailer tongue or in the towing vehicle to run while in motion. Alternatively, the high-quality insulation keeps goods cold for shorter trips without power.
7. How long does it take to reach the desired temperature?
An empty trailer typically pulls down to 0°C (32°F) within 30 to 60 minutes, depending on the ambient temperature and the power of the cooling unit.
8. How much power does the unit consume?
Power consumption varies by model, but most compact units are energy-efficient, drawing between 10 to 15 amps during startup and significantly less while running.
9. Is there a backup power option?
We recommend using a portable generator (usually 3.5kW or higher) as a backup power source if shore power is unavailable.
10. What kind of vehicle do I need to tow this trailer?
Our single-axle compact models are lightweight and can be towed by most standard SUVs, pickup trucks, and even some sedans. Please check your vehicle's towing capacity against the trailer's Gross Vehicle Weight (GVW).
11. Do I need a special driver’s license to tow this?
For most small to medium-sized trailers (under 3,500kg or 7,700lbs), a standard driver’s license is sufficient. However, regulations vary by country and state, so please check local laws.
12. What type of connection does the trailer lights use?
We install standard 7-pin (round) or flat connectors adaptable to most vehicles.
13. What is the payload capacity?
Payload depends on the specific axle rating. A standard single-axle unit typically carries between 500kg to 1,000kg (1,100lbs to 2,200lbs). Heavy-duty options are available.
14. What material is the insulation made of?
We use high-density Polyurethane (PU) sandwich panels (typically 75mm to 100mm thick), which offer superior thermal efficiency compared to Styrofoam.
15. Is the floor slip-resistant?
Yes, the floor is typically finished with checkered aluminum plate (diamond plate) or an anti-slip resin coating to ensure safety during loading and unloading.
16. Does it come with internal shelving?
Shelving is optional. We can install stainless steel or food-grade wire racking, or leave the space open for pallet storage.
17. Is the interior light waterproof?
Yes, the trailer comes equipped with an IP65-rated LED internal light for safe operation in wet and cold conditions.
18. Are the doors lockable?
Yes, the rear doors feature heavy-duty stainless steel cam-locks that are fully lockable to secure your valuable cargo.
19. Is there an emergency release inside?
Safety is a priority. All our walk-in trailers feature an internal safety release mechanism, allowing anyone trapped inside to open the door easily.
20. How do I clean the interior?
The interior panels are seamless and water-resistant. You can wash them down with mild detergent and water. A floor drain is usually included for easy washout.
21. How often does the refrigeration unit need servicing?
We recommend a basic check-up (cleaning condenser coils, checking refrigerant levels) once a year or every 6 months if used heavily.
22. What should I do if the unit stops working?
Check your power source and breakers first. If the issue persists, our units are made by major manufacturers (like Govi, KingClima, or Carrier), so parts and service technicians are widely available.
23. Can I customize the size or color?
Yes, we offer OEM/ODM services. We can customize dimensions, door placement, exterior wrap/branding, and chassis specifications.
24. What is the warranty period?
We typically offer a 1-year warranty on the trailer chassis and body, and a separate warranty (usually 1 year) from the refrigeration unit manufacturer.
25. Do you ship internationally?
Yes, we ship worldwide. Trailers can be shipped fully assembled (CBU) or in flat-pack (CKD) form to save on shipping costs.
